Tab

Tab component

Basic Usage

Combine er-tab with er-tab-panel, and you'll get a tabs component. You can set the current active by v-model property . You also can change the size or type by set the property.

vue

<script lang="ts" setup>
import { ref } from 'vue'
const activeName = ref('begin')
</script>

<template>
  <er-tab v-model="activeName">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
</template>

<style scoped></style>

<script lang="ts" setup>
import { ref } from 'vue'
const activeName = ref('begin')
</script>

<template>
  <er-tab v-model="activeName">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
</template>

<style scoped></style>

Different size

To change the display size to small large, you can set the size property. The default size is default.

Current: default

vue

<template>
  <er-tab :size="size">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
  <er-button @click="change"> default/small/large </er-button>
  <span> Current: {{ size }}</span>
</template>

<script lang="ts" setup>
import { ref } from 'vue'
const activeName = ref('begin')
const size = ref('default')

let list = ['small', 'large', 'default']
const change = () => {
  size.value = list[0]
  list = [...list.slice(1), list[0]]
}
</script>

<style scoped></style>

<template>
  <er-tab :size="size">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
  <er-button @click="change"> default/small/large </er-button>
  <span> Current: {{ size }}</span>
</template>

<script lang="ts" setup>
import { ref } from 'vue'
const activeName = ref('begin')
const size = ref('default')

let list = ['small', 'large', 'default']
const change = () => {
  size.value = list[0]
  list = [...list.slice(1), list[0]]
}
</script>

<style scoped></style>

Different Position

Current: top

vue

<template>
  <er-tab :tab-position="position">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
  <er-button @click="change"> right/bottom/left/top </er-button>
  <span> Current: {{ position }}</span>
</template>

<script lang="ts" setup>
import { ref } from 'vue'
const position = ref('top')

let list = ['right', 'bottom', 'left', 'top']
const change = () => {
  position.value = list[0]
  list = [...list.slice(1), list[0]]
}
</script>

<style scoped></style>

<template>
  <er-tab :tab-position="position">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
  <er-button @click="change"> right/bottom/left/top </er-button>
  <span> Current: {{ position }}</span>
</template>

<script lang="ts" setup>
import { ref } from 'vue'
const position = ref('top')

let list = ['right', 'bottom', 'left', 'top']
const change = () => {
  position.value = list[0]
  list = [...list.slice(1), list[0]]
}
</script>

<style scoped></style>

Different type

You can set the type card border-card to change the showMode

Current: default

vue

<template>
  <er-tab :type="type">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
  <er-button @click="change"> card/border-card/default </er-button>
  <span> Current: {{ type || 'default' }}</span>
</template>

<script lang="ts" setup>
import { ref } from 'vue'
const type = ref('')

let list = ['card', 'border-card', '']
const change = () => {
  type.value = list[0]
  list = [...list.slice(1), list[0]]
}
</script>

<style scoped></style>

<template>
  <er-tab :type="type">
    <er-tab-panel label="开始" name="begin">1</er-tab-panel>
    <er-tab-panel label="下单" name="order">2</er-tab-panel>
    <er-tab-panel label="审核" name="approval">3</er-tab-panel>
    <er-tab-panel label="流程结束" name="end">4</er-tab-panel>
  </er-tab>
  <er-button @click="change"> card/border-card/default </er-button>
  <span> Current: {{ type || 'default' }}</span>
</template>

<script lang="ts" setup>
import { ref } from 'vue'
const type = ref('')

let list = ['card', 'border-card', '']
const change = () => {
  type.value = list[0]
  list = [...list.slice(1), list[0]]
}
</script>

<style scoped></style>

Tabs API

Tabs Attributes

Name	Description	Type	Default
v-model	Set the active Tab	`string \| number`	-
size	Set the size	`'large' \| 'small' \| 'default'`	default
type	Set the show Mode	`'card' \| 'border-card'`	-
tabPosition	Set the tabs direction	`'left' \| 'right' \| 'top' \| 'bottom'`	top

Tabs Event

Name	Description	Parameters
tab-click	trigger it when click the tab	`item: Children, index: number`

TabsPanel Attributes

Name	Description	Type	Default
label	Set show tab title	`string`	-
name	Set the unqiue value of the tab	`string`	-
